looks like the last thing but they aren’t related
// made by alex
// iamalexbaker@gmail.com
// dailygenerative.art.blog
// with variables in sets like {a, b, c}, a is the minimum and b is the maximum, a random value will be chosen in that range
float limit = 800;
float startR = 100;
float endR = 800;
float[] circle = {100, 5000, 200};
int[] numArcs = {100, 4000, 1000};
int[] offset = {0, 0, 0};
float[] startAngle = {0, TWO_PI, 0};
float alpha = 16;
float[] hue = {0, TWO_PI, 0};
float[] sat = {0, 0.7, 0};
float[] bri = {0, 0.8, 0};
int colourMode = 2; // -1 = solid colour, 0 = interp through radius, 1: interp through angle, 2: interp based on line length
int nc = 2;
color[] c = new color[nc];
color bgc, lc;
ArrayList<Integer> numbers;
int count = 1;
int index = 0;
ArrayList<Integer> sequence;
float r = startR;
float ri = 0.1;
void setup(){
size(800,800);
smooth(4);
colorMode(HSB, TWO_PI, 1, 1);
bgc = color(0, 0, 0.8);
for(int i = 0; i < nc; i++){
c[i] = color(random(hue[0], hue[1]), random(sat[0], sat[1]), random(bri[0], bri[1]));
}
background(bgc);
numbers = new ArrayList<Integer>();
sequence = new ArrayList<Integer>();
startAngle[2] = random(startAngle[0], startAngle[1]);
numArcs[2] = int(random(numArcs[0], numArcs[1]));
circle[2] = random(circle[0], circle[1]);
count = int(random(offset[0], offset[1]));
println("Count offset: "+count);
println("Start angle: "+(startAngle[2]/PI)+"PI");
println("Num arcs: "+numArcs[2]);
println("Circumference units: "+circle[2]);
index = 0;
r = startR;
ri = (endR - startR) / float(numArcs[2]);
noFill();
stroke(255);
for(int i = 0; i < numArcs[2]; i++){
step();
}
}
void draw(){
}
void step(){
pushMatrix();
int next = index - count;
int dir = -1;
if(next <= 0 || numbers.contains(next)){
next = index + count;
dir = 1;
}
float t1 = ((float(index) % circle[2]) / circle[2]) * TWO_PI;
t1 = ((float(min(index,next)) % circle[2]) / circle[2]) * TWO_PI;
float angle = ((float(abs(next-index)) % circle[2]) / circle[2]) * TWO_PI; //println(t2-t1);
//println(angle+ " :: "+t1+ " ---"+float(index)%circle + " " + float(next)%circle);
translate(width/2, height/2);
rotate(t1 + startAngle[2]);
color colour = c[0];
switch(colourMode){
default:
case -1:
break;
case 0:
colour = lerpColor(c[0], c[1], r/endR);
break;
case 1:
colour = lerpColor(c[0], c[1], t1/TWO_PI);
break;
case 2:
//colour = (dir>0)?c[0]:c[1]; // doesn't really work like I wanted
colour = lerpColor(c[0], c[1], angle/TWO_PI);
break;
}
stroke(colour, alpha);
noFill();
arc(0, 0, r, r, 0, angle);
numbers.add(next);
sequence.add(next);
index = next;
count++;
r += ri;
popMatrix();
}
void keyPressed()
{
if (keyCode==32) { // space
String fn = "reca-"+hour()+"-"+minute()+"-"+second()+".png";
saveFrame(fn);
println("Saved image "+fn);
}
if (keyCode==10) { // enter
setup();
println("Initialising new state");
}
}
