// made by alex
// iamalexbaker@gmail.com
// dailygenerative.art.blog
// still a WIP - lots of things haven't been implemented yet
// raycast vars
float c_size = 1;
int show_boundaries = 0;
int[] num_walls = {1,8};
boolean[] symmetry = {true, true}; // simple x, y symmetry
int startMode = 1; // 0 - random, 1 - in circle
float spawnCircleRadius = 100;
boolean wrapCircle = true;
boolean hardWrap = true;
boolean allowReturn = false;
float wrapRadius = 250;
float wrapStrength = 0.15;
// collatz vars
float[] len = {10, 24};
float[] angle = {-PI/2, PI/2, 0};
int[] start = {1000000, 2000000, 0};
int[] num = {100, 3000, 0};
float[] size = {1, 5, 0};
float[] weights = {50,5,1,10}; // probability of {line, circle, both, blank}
boolean drawHairs = false; // nice with either low numbers of lines, or long scale and wide len range
float[] hairScale = {1.2, 5.5, 0}; // multiple of the length of the main line (len variable)
int hairColourMode = 0; // 0 = white, 1 = c[0], 2 = c[1], 3 = cc (lerp), 4 = bgc, 5 = black
int numCycles = 10;
// colour vars
float[] hueRange = {0, TWO_PI};
float[] satRange = {0.2, 0.9};
float[] briRange = {0.2, 1.0};
float alpha = 10;
int nc = 4;
color[] c = new color[nc];
color fixedColour;
color bgc;
float hue, sat, bri;
boolean do_draw = true;
ArrayList<boundary> walls = new ArrayList<boundary>();
PVector origin, centre;
boundary lastHit;
void setup(){
size(800,800);
do_draw = true;
nnn = 0;
lastHit = null;
colorMode(HSB, TWO_PI, 1, 1);
bgc = color(0, 0, 0.8); // * 0.2 and * 0.8 are both nice
background(bgc);
colourSetup();
originSetup();
wallSetup();
}
void originSetup(){
centre = new PVector(width/2, height/2);
origin = new PVector(random(width-2)+1,random(height-2)+1);
if(startMode == 1){
float r = random(spawnCircleRadius);
float t = random(TWO_PI);
origin.x = r * cos(t) + width/2;
origin.y = r * sin(t) + height/2;
}
start[2] = int(random(start[0], start[1]));
num[2] = int(random(num[0], num[1]));
size[2] = random(size[0], size[1]);
angle[2] = random(angle[0], angle[1]);
}
void wallSetup(){
walls.clear();
// boundaries of screen
walls.add(new boundary(0,0,width,0));
walls.add(new boundary(0,0,0,height));
walls.add(new boundary(0,height,width,height));
walls.add(new boundary(width,0,width,height));
// generate boundaries
float n_walls = random(num_walls[1]-num_walls[0])+num_walls[0];
for (int i = 0; i < n_walls; i++) {
walls.add(new boundary(random(width), random(height), random(width), random(height)));
}
}
void colourSetup(){
fixedColour = color(PI, PI, PI);
hue = random(hueRange[0], hueRange[1]);
sat = random(satRange[0], satRange[1]);
bri = random(briRange[0], briRange[1]);
for(int i = 0; i < nc; i++){
c[i] = color(random(hueRange[0], hueRange[1]), random(satRange[0], satRange[1]), random(briRange[0], briRange[1]));
}
}
void draw(){
if(!do_draw) return;
background(bgc);
if(show_boundaries == 1){
for (boundary wall : walls) {
wall.show();
}
}
//ellipse(origin.x, origin.y, 10, 10);
for(int i = 0; i < numCycles; i++){
colourSetup();
originSetup();
cycle(start[2], start[2]+num[2], angle[2], 0, origin);
}
do_draw = false;
}
void cycle(int s, int e, float a, float r, PVector o)
{
for (int i = s; i < e; i++) {
LongList seq = new LongList();
resetMatrix();
long n = i;
do {
seq.append(n);
n = collatz(n);
} while (n != 1);
seq.append(1);
seq.reverse();
float rot = r;
PVector _pos = origin;
for (int j = 0; j < seq.size(); j++)
{
fill(0,0.3,0.6);
stroke(0,0.3,0.6);
//line(_pos.x, _pos.y, _pos.x + PVector.fromAngle(rot).x * 110, _pos.y + PVector.fromAngle(rot).y * 110);
float l = random(len[0], len[1]);
color cc = lerpColor(c[0], c[1], float(j)/seq.size());
if(drawHairs){
color hc;
switch(hairColourMode){
default:
case 0: hc = color(0, 0, 1); break;
case 1: hc = c[0]; break;
case 2: hc = c[1]; break;
case 3: hc = cc; break;
case 4: hc = bgc; break;
case 5: hc = color(0, 0, 0); break;
}
ray _r2 = new ray(_pos.x, _pos.y, PVector.fromAngle(rot), 1, 0.01, hc, selectWeighted(weights));
hit h2 = _r2.multicast(walls, l * random(hairScale[0], hairScale[1]));
_r2.show(h2);
}
ray _ray = new ray(_pos.x, _pos.y, PVector.fromAngle(rot), 1, 0.01, cc, selectWeighted(weights));
//line(_ray.pos.x, _ray.pos.y, _ray.pos.x + _ray.dir.x * 80, _ray.pos.y + _ray.dir.y * 80);
hit h = _ray.multicast(walls, l);
if(h != null){
_ray.show(h);
_pos = h.p;
if(h.realHit){
rot = _ray.reflectionAngle(h);
lastHit = h.b;
}
else{
lastHit = null;
if(h.wrapped) rot = h.facing;
if(!h.wrapped || !hardWrap){
long value = seq.get(j);
if (value % 2 == 0) {
rot += a;
} else {
rot -= a;
}
}
}
}
//int t = selectWeighted(weights);
//switch(t){
// case 1:
// ellipse(0, 0, size[2], size[2]);
// break;
// case 2:
// rect(0, 0, size[2], size[2]);
// break;
// default:
// case 3:
// break;
// case 0:
// line(0, 0, 0, l);
// break;
//}
//translate(0, l);
}
}
}
class boundary {
PVector a, b;
PVector[] normal;
float m, c;
boundary(float x1, float y1, float x2, float y2) {
if(x1 < x2){
a = new PVector(x1, y1);
b = new PVector(x2, y2);
m = (y2-y1)/(x2-x1);
} else {
b = new PVector(x1, y1);
a = new PVector(x2, y2);
m = (y1-y2)/(x1-x2);
}
c = y1 - m*x1;
normal = new PVector[2];
normal[0] = PVector.fromAngle(atan2(b.y - a.y, b.x - a.x)+PI/2);
normal[1] = PVector.fromAngle(atan2(b.y - a.y, b.x - a.x)-PI/2);
}
boolean containsPoint(PVector pt){
return (pt.y == m*pt.x + c);
}
void show() {
fill(0, 1, 1);
ellipse(a.x, a.y, 5, 5);
fill(PI, 1, 1);
ellipse(b.x, b.y, 5, 5);
stroke(0,0,1);
line(a.x, a.y, b.x, b.y);
float xx = a.x + (b.x-a.x)/2;
float yy = a.y + (b.y-a.y)/2;
line(xx, yy, xx+normal[0].x*10, yy+normal[0].y*10);
stroke(0, 0.5, 1);
line(xx, yy, xx+normal[1].x*10, yy+normal[1].y*10);
}
}
class ray {
PVector pos, dir;
float power;
float power_drop;
color colour;
int show_mode = 0;
ray(float x, float y, PVector d, float p, float pd, color cc, int mode) {
pos = new PVector(x, y);
dir = d;
power = p;
power_drop = pd;
colour = cc;
show_mode = mode;
}
void show(hit h) {
if(show_mode == 0 || show_mode == 2){
stroke(colour, alpha);
symmLine(pos.x, pos.y, h.p.x, h.p.y);
}
if(show_mode == 1 || show_mode == 2){
noStroke();
fill(colour, alpha);
symmEllipse(h.p.x, h.p.y);
}
}
void symmLine(float x1, float y1, float x2, float y2){
line(x1, y1, x2, y2);
if(symmetry[0]) line(x1, height - y1, x2, height - y2);
if(symmetry[1]) line(width - x1, y1, width - x2, y2);
if(symmetry[0] && symmetry[1]) line(width - x1, height - y1, width - x2, height - y2);
}
void symmEllipse(float x, float y){
ellipse(x, y, c_size * power, c_size * power);
if(symmetry[0]) ellipse(x, height - y, c_size * power, c_size * power);
if(symmetry[1]) ellipse(width - x, y, c_size * power, c_size * power);
if(symmetry[0] && symmetry[1]) ellipse(width - x, height - y, c_size * power, c_size * power);
}
PVector cast(boundary b) {
// https://en.wikipedia.org/wiki/Line–line_intersection
float x1, x2, x3, x4, y1, y2, y3, y4, d, t, u, hx, hy;
x1 = b.a.x;
y1 = b.a.y;
x2 = b.b.x;
y2 = b.b.y;
x3 = pos.x;
y3 = pos.y;
x4 = pos.x + dir.x;
y4 = pos.y + dir.y;
d = (x1 - x2) * (y3 - y4) - (y1 - y2) * (x3 - x4);
if (d==0) return null;
t = ((x1 - x3) * (y3 - y4) - (y1 - y3) * (x3 - x4)) / d;
u = - ((x1 - x2) * (y1 - y3) - (y1 - y2) * (x1 - x3)) / d;
if (t > 0 && t < 1 && u > 0) {
hx = x1 + t * (x2-x1);
hy = y1 + t * (y2-y1);
return new PVector(hx, hy);
} else return null;
}
hit multicast(ArrayList<boundary> walls, float distanceLimit)
{
float record = Float.POSITIVE_INFINITY;
PVector hp;
float d;
hit h;
PVector pt = new PVector(0,0);
boundary b = walls.get(1);
// find nearest boundary, so ray doesn't hit multiple walls
for(boundary wall : walls){
if(wall == lastHit) continue; // IMPORTANT - this stops the bug where rays can pass through walls
hp = cast(wall);
if(hp != null){
d = pos.dist(hp);
if(d < record){
record = d;
pt = hp;
b = wall;
}
}
}
if(record < distanceLimit){
h = new hit(pt, b, true);
} else {
pt.x = pos.x + dir.x * distanceLimit;
pt.y = pos.y + dir.y * distanceLimit;
h = new hit(pt, b, false);
}
if(wrapCircle){
float ptdist = pt.dist(centre);
float sdist = pos.dist(centre);
if(ptdist > wrapRadius && (!allowReturn || ptdist > sdist)){
PVector facing = new PVector(pt.x - pos.x, pt.y - pos.y);
PVector intoCircle = new PVector(centre.x - pos.x, centre.y - pos.y).normalize();
float facingMag = facing.mag();
facing.normalize();
PVector tangent = intoCircle.copy().rotate(PI/wrapRadius);
facing.lerp(tangent, wrapStrength);
h.wrapped = true;
h.facing = facing.heading();
facing.setMag(facingMag);
h.p = pos.add(facing);
}
}
return h;
}
void recursivecast(ArrayList<boundary> walls)
{
hit h = multicast(walls, Float.POSITIVE_INFINITY);
if(h != null)
{
show(h); // show this ray
// calculate reflection
PVector ref = PVector.sub(dir, PVector.mult(h.b.normal[0], PVector.dot(dir, h.b.normal[0])*2));
// reduce power, cast next ray (reflection) if it still has power
// --currently unused
if(power-power_drop > 0){
ray r = new ray(h.p.x,h.p.y,ref,power-power_drop,power_drop, colour, show_mode);
r.recursivecast(walls);
}
}
}
float reflectionAngle(hit h){
float d = (h.p.x - h.b.a.x)*(h.b.b.y - h.b.a.y) - (h.p.y - h.b.a.y)*(h.b.b.x - h.b.a.x);
//println(d);
int normalIndex = 0;//(d < 0)?1:0;
PVector refAngle = PVector.sub(dir, PVector.mult(h.b.normal[normalIndex], PVector.dot(dir, h.b.normal[normalIndex])*2));
float rot = refAngle.heading();
//stroke(0,0.5,0.5);
//fill(0,0.5,0.5);
//line(pos.x, pos.y, pos.x + dir.x * 100, pos.y + dir.y * 100);
//text(nnn, pos.x + dir.x * 100, pos.y + dir.y * 100);
//println(nnn+": "+degrees(dir.heading())+" -> "+degrees(rot)+" :: "+h.b.containsPoint(h.p));
//ellipse(h.p.x, h.p.y, 5, 5);
//fill(0,0,0);
//stroke(0,0,0);
//line(h.p.x, h.p.y, h.p.x + refAngle.x*100, h.p.y + refAngle.y*100);
//text(nnn, h.p.x + refAngle.x*100, h.p.y + refAngle.y*100);
nnn++;
return rot;
}
void lookAt(float x, float y) {
dir.x = x - pos.x;
dir.y = y - pos.y;
dir.normalize();
}
}
int nnn = 0;
class hit{
PVector p;
boundary b;
boolean realHit;
boolean wrapped;
float facing;
hit(PVector pp, boundary bb, boolean rh){
p = pp; b = bb; realHit = rh;
}
}
long collatz(long n) {
if (n % 2 == 0) {
return n / 2;
} else {
return (3*n + 1) / 2;
}
}
// function to randomly select an array index from an array of weights
int selectWeighted(float[] w){
int total = 0;
for(float ww: w) total += ww;
float r = random(total);
int n = 0;
for(float ww: w){
r -= ww;
if(r <= 0) return n;
n++;
}
return w.length;
}
void keyPressed()
{
if (keyCode==32) { // press space to save
saveFrame("crfnsy-"+hour()+"-"+minute()+"-"+second()+".png");
}
if (keyCode==10) { // press enter to reset
setup();
}
}
