interdimensional spiders

// made by alex
// iamalexbaker@gmail.com
// dailygenerative.art.blog
//
// interdimensional spiders
//
// casts a bunch of rays rotating around an origin.
// when they collide with a set of boundaries, their heading is attracted in
// towards them by an amount depending on the boundary.
// the rays lose power after each collision and eventually die off

float c_size = 15;
boolean buggy_walls = false;
int[] num_walls = {1,15};
float power_start = 0.7;
float[] power_dec = {0.01,0.08};
float[] start_angle = {0,360}; // all parameters with a range get a random value each run
float[] finish_angle = {0,360};
float[] angle_inc = {0.1,3.0};
boolean show_boundaries = false;
int split_count = 5;
int hit_mode = 0; // 0 = lines, 1 = circles, 2 = both
float[] turn_amt = {0.2, 0.8, 0.1};
boolean diff_turn_amts = true;
boolean random_turn_dir = true;

float[] hueRange = {0, TWO_PI};
float[] satRange = {0, 0.7};
float[] briRange = {0.4, 0.8};
float alpha = 255;
float strokeWeight = 1;
int nc = 3;
color[] c = new color[nc];
color bgc;
float hue, sat, bri;

boolean do_draw = true;
PVector origin;
ArrayList<boundary> walls = new ArrayList<boundary>();
ArrayList<ray> rays = new ArrayList<ray>();

class boundary {
  PVector a, b, normal, dir;
  float r;
  boolean mode; // false = reflect, true = refract

  boundary(float x1, float y1, float x2, float y2, float _r, boolean m) {
    a = new PVector(x1, y1);
    b = new PVector(x2, y2);
    normal = PVector.fromAngle(atan2(b.y - a.y, b.x - a.x)-PI/2);
    dir = new PVector(b.x - a.x, b.y - a.y).normalize();
    r = _r; mode = m;
  }

  void show() {
    stroke(0,0,1);
    line(a.x, a.y, b.x, b.y);
    float xx = a.x + (b.x-a.x)/2;
    float yy = a.y + (b.y-a.y)/2;
    //line(xx,yy,xx+normal.x*10,yy+normal.y*10);
  }
}

class ray {
  PVector pos, dir;
  float power;
  float power_drop;
  color[] colour;
  int show_mode = 0;
  int generation;
  float refr_angle;
  ray(float x, float y, PVector d, float p, float pd, color[] cc, int mode, int g, float ra) {
    pos = new PVector(x, y);
    dir = d;
    power = p;
    power_drop = pd;
    colour = cc;
    show_mode = mode;
    generation = g;
    refr_angle = ra;
  }
  void show(hit h) {
    if(show_mode == 0 || show_mode == 2){
      stroke(lerpColor(colour[0],colour[1],power), power*alpha);
      line(pos.x, pos.y, h.p.x, h.p.y);
    }
    if(show_mode == 1 || show_mode == 2){
      noStroke();
      fill(lerpColor(colour[0],colour[1],power), power*alpha);
      ellipse(h.p.x, h.p.y, c_size*power, c_size*power);
    }
  }

  PVector cast(boundary b) {
    // https://en.wikipedia.org/wiki/Line–line_intersection
    float x1, x2, x3, x4, y1, y2, y3, y4, d, t, u, hx, hy;
    x1 = b.a.x;
    y1 = b.a.y;
    x2 = b.b.x;
    y2 = b.b.y;
    x3 = pos.x;
    y3 = pos.y;
    x4 = pos.x + dir.x;
    y4 = pos.y + dir.y;

    d = (x1 - x2) * (y3 - y4) - (y1 - y2) * (x3 - x4);
    if (d==0) return null;

    t = ((x1 - x3) * (y3 - y4) - (y1 - y3) * (x3 - x4)) / d;
    u = - ((x1 - x2) * (y1 - y3) - (y1 - y2) * (x1 - x3)) / d;

    if (t > 0 && t < 1 && u > 0) {
      hx = x1 + t * (x2-x1);
      hy = y1 + t * (y2-y1);
      return new PVector(hx, hy);
    } else return null;
  }
  hit multicast(ArrayList<boundary> walls, boundary lastHit)
  {
    float record = Float.POSITIVE_INFINITY;
    PVector h;
    float d;
    PVector pt = new PVector(0,0);;
    boundary b = walls.get(1);
    // find nearest boundary, so ray doesn't hit multiple walls
    for(boundary wall : walls){
      if(wall == lastHit && !buggy_walls) continue; // IMPORTANT - this stops the bug where rays can pass through walls
      h = cast(wall);
      if(h != null){
        d = pos.dist(h);
        if(d < record){
          record = d;
          pt = h;
          b = wall;
        }
      }
    }
    if(record < Float.POSITIVE_INFINITY){
      return new hit(pt, b);
    } else return null;
  }
  void recursivecast(ArrayList<boundary> walls, boundary lastHit)
  {
    hit h = multicast(walls, lastHit);
    if(h != null)
    {
      show(h); // show this ray


      // reduce power, cast next ray if it still has power
      if(power-power_drop > 0){
          PVector ref = PVector.sub(dir, PVector.mult(h.b.normal, PVector.dot(dir, h.b.normal)*2)); // reflect if it's a hard boundary (edge of screen)
          PVector tdir = (random_turn_dir&&random(1)>0.5)?h.b.dir.mult(-1):h.b.dir;
          ray r = new ray(h.p.x, h.p.y,(h.b.mode)?ref:dir.lerp(tdir, h.b.r), power-power_drop, power_drop, colour, show_mode, generation+1, 0);
          r.recursivecast(walls, h.b);
      }
    }
  }
  void lookAt(float x, float y) {
    dir.x = x - pos.x;
    dir.y = y - pos.y;
    dir.normalize();
  }
}

class hit{
  PVector p;
  boundary b;

  hit(PVector pp, boundary bb){
    p = pp; b = bb;
  }
}

void setup(){
  size(800, 800);
  do_draw = true;
  origin = new PVector(random(width-2)+1,random(height-2)+1);
  rays.clear();

  colorMode(HSB, TWO_PI, 1, 1);
  bgc = color(0, 0, 0.2);
  hue = random(hueRange[0], hueRange[1]);
  sat = random(satRange[0], satRange[1]) * TWO_PI;
  bri = random(briRange[0], briRange[1]) * TWO_PI;
  for(int i = 0; i < nc; i++){
    c[i] = color(random(hueRange[0], hueRange[1]), random(satRange[0], satRange[1]), random(briRange[0], briRange[1]));
  }

  // set random variables in defined ranges
  float start = random(start_angle[1]-start_angle[0])+start_angle[0];
  float finish = random(finish_angle[1]-finish_angle[0])+finish_angle[0];
  float ang_inc = random(angle_inc[1]-angle_inc[0])+angle_inc[0];
  float p_d = random(power_dec[1]-power_dec[0])+power_dec[0];
  turn_amt[2] = random(turn_amt[0], turn_amt[1]);

  // if finish < start, swap values
  if(finish<=start){
    float t = start;
    start = finish;
    finish = t;
  }

  // boundaries of screen
  walls.clear();
  walls.add(new boundary(0, 0, width, 0, 1, true));
  walls.add(new boundary(0, 0, 0, height, 1, true));
  walls.add(new boundary(0, height, width, height, 1, true));
  walls.add(new boundary(width, 0, width, height, 1, true));

  // generate boundaries
  float n_walls = random(num_walls[1]-num_walls[0])+num_walls[0];
  for (int i = 0; i < n_walls; i++) {
    if(diff_turn_amts) turn_amt[2] = random(turn_amt[0], turn_amt[1]);
    walls.add(new boundary(random(width), random(height), random(width), random(height), turn_amt[2], false));
  }

    // rotate through range and generate initial rays
  for (float i = start; i < finish; i+=ang_inc)
  {
    color[] cc = {c[0], c[1]};
    rays.add(new ray(origin.x, origin.y, PVector.fromAngle(radians(i)), power_start, p_d, cc, hit_mode, 0, -1));
  }
}

void draw(){
  if(!do_draw) return;

  background(bgc);
  if(show_boundaries){
    for (boundary wall : walls) {
      wall.show();
    }
  }

  for (ray r : rays) {
    r.recursivecast(walls, null);
  }

  do_draw = false;
}

void keyPressed()
{
  if(keyCode==32){
    saveFrame("tl-"+hour()+"-"+minute()+"-"+second()+".png");
  }
  if(keyCode==10){
     setup();
  }
}
